  • 20Hp Wheel Tractor

20Hp Wheel Tractor

Dual-function clutch,Twin turning speeds of P.T.O.,Power steering

We're here to help: Easy ways to get the answers you need.

Send Email Chat Now

Describe ParameterRelated products Inquiry

Describe

MODEL DF-200/DF-204

Main Dispositions:

Dual-function clutch
Twin turning speeds of P.T.O.
Power steering
Safe start switch
Fiberglass hood
Combination meters
Quality seat system
Seat belt

Options:

Folding ROPS
Sun shade
Spring seat system
Turf tyre
Industrial tyre
EPA Engine
Hydraulic outlet


Parameter

Tractor Parameters Model DF-200 DF-204
Drive Type 2WD 4WD
Overall Dimensions 2800×1350×1460 2800×1350×1460
L×W×H(mm) Height steering wheel Height steering wheel
Wheel Track(mm) Front 975(Usually use) 984
117,512,751,375
Rear 1,020,112,012,201,320 1,020,112,012,201,320
Wheel Base(mm) 1619 1638
Ground Under Front Axle 400 292
Clearancre(mm) Under Rear Axle 290 290
Rated Traction In Paddy Fields 3600 4435
Force(N) In Dry Fields 5250 6410
Construction Mass(Kg) 1040 1190
Min. Turning Radius(m) 2.4 2.4
Theoretical Forward 1.11,1.29,2.90,5.06,5.75,9.26,15.02,26.20 1.11,1.29,2.90,5.06,5.75,9.26,15.02,26.20
Speed(Km/h) Reverse 1.44,7.45 1.44,7.45
Engine Specifications Model Y380T Y380T
Type 3-cylinder,Upright inline cylinder,radiator cooling,4-storke cycle 3-cylinder,Upright inline cylinder,radiator cooling,4-storke cycle
12-hour Rated Power(Kw/hp) 14.7/20.0 14.7/20.0
Rated Speed(rpm) 2400 2400
Bore×Stroke(mm) 80×90 80×90
Total Displacement(L) 1.375 1.375
Drive System Clutch Dual-stage Dual-stage
Gear Box (4+1)×2 (4+1)×2
Main Drive One Pair of Spiral Bevel gears One Pair of Spiral Bevel gears
Differential Bevel Gear Bevel Gear
Differential Lock Jaw Lock Jaw Lock
Final Transmissions Spur Gear,External Gearing Spur Gear,External Gearing
Travelling Mechanism Tyre front 4.00-16(stripe pattern) 6.00-12(herringbone pattern)
rear 8.3-24(herringbone pattern) 8.3-24(herringbone pattern)
Steering Gear Full Hydraulic steering Full Hydraulic steering
Brake Disk type Disk type
Working Device Hydraulic System Lifting Capacity at 610 mm Behind Lift Point(Kg) 432kg 432kg
3-point Suspension Category:I Category:I
P.T.O.Shaft Rotating Speed(rpm) 540/1000 540/1000
Spline size 6-φ35 Rectangular spline 6-φ35 Rectangular spline
