| Tractor Parameters |
|
DF-254G2 |
DF-304G2 |
DF-354G2/404G2 |
| Drive Type |
4WD |
4WD |
4WD |
| Overall Dimensions |
3269×1567×1556 |
3302×1632×1512 |
3332×1632×1575 |
| L×W×H(mm) |
| Wheel Track(mm) |
Front |
1185 |
1200 |
1200 |
| |
Rear |
1240 |
1242 |
1242 |
| Wheel Base(mm) |
1700 |
1730 |
1824/1856 |
| Ground Clearancre(mm) |
Under Front Axle |
300 |
300 |
358 |
| Under Rear Axle |
345 |
345 |
403 |
| Rated Traction Force(N) |
In Paddy Fields |
3920 |
4950 |
5160 |
| In Dry Fields |
5800 |
6940 |
7230 |
| Construction Mass(Kg) |
1460 |
1560 |
1680 |
| Min. Turning Radius(m) |
2.3 |
2.4 |
2.5 |
| Theoretical Speed(Km/h) |
Forward |
1.28,1.86,2.98,4.50,6.65,9.63,15.45,23.33 |
1.28,1.86,2.98,4.50,6.65,9.63,15.45,23.33 |
1.42, 2.06, 3.30, 4.98, 7.36, 10.65, 17.09, 25.81 |
| Reverse |
1.29,1.87,3.00,4.53,6.70,9.70,15.56,23.50 |
1.29,1.87,3.00,4.53,6.70,9.70,15.56,23.50 |
1.43, 2.07, 3.32, 5.02, 7.41, 10.73, 17.21, 26.00 |
| Engine Specifications |
Model |
Y385T |
ZN390T |
TY395l |
| Type |
3-cylinder,4-storke cycle,radiator cooling |
3-cylinder,4-storke cycle,radiator cooling |
3-cylinder,4-storke cycle,radiator cooling |
| 12-hour Rated Power(Kw/hp) |
18.4/25.0 |
22.0/30.0 |
25.8/35.0 |
| Rated Speed(rpm) |
2350 |
2500 |
2400 |
| Bore×Stroke(mm) |
85×90 |
90×95 |
95×105 |
| Total Displacement(L) |
1.532 |
1.812 |
2.23 |
| Drive System |
Clutch |
Dual-stage |
Dual-stage |
Dual-stage |
| Gear Box |
(4+4)×2 Shuttle shift syuchmesh |
(4+4)×2 Shuttle shift syuchmesh |
(4+1)×2×2 Shuttle shift syuchmesh |
| Main Drive |
One Pair of Spiral Bevel gears |
One Pair of Spiral Bevel gears |
One Pair of Spiral Bevel gears |
| Differential |
Bevel Gear |
Bevel Gear |
Bevel Gear |
| Differential Lock |
Jaw Lock |
Jaw Lock |
Jaw Lock |
| Final Transmissions |
Spur Gear,External Gearing |
Spur Gear,External Gearing |
Spur Gear,External Gearing |
| Travelling Mechanism |
Tyre |
front |
6.00-12(stripe pattern) |
6.50-16(stripe pattern) |
7.50-16(herringbone pattern) |
| rear |
8.3-24(herringbone pattern) |
11.2-24(herringbone pattern) |
12.4-24(herringbone pattern) |
| Steering Gear |
Full Hydraulic steering |
Full Hydraulic steering |
Full Hydraulic steering |
| Brake |
Disk type |
Disk type |
Disk type |
| Working Device |
Hydraulic System |
Lifting Capacity at 610 mm Behind Lift Point(Kg) |
415kg |
415kg |
475 |
| 3-point Suspension |
Category:I |
Category:I |
Category:I |
| P.T.O.Shaft |
Rotating Speed(rpm) |
540/1000 |
540/1000 |
540/1000 |
| Spline size |
6-φ35 Rectangular spline |
6-φ35 Rectangular spline |
6-φ35 Rectangular spline |
