Tractor Parameters
|
Model
|
DF-900
|
DF-904
|
DF-950
|
DF-954
|
|
Drive Type
|
2WD
|
4WD
|
2WD
|
4WD
|
|
Overall Dimensions L×W×H (mm)
|
4255×2100×2850
|
|
Wheel Track (mm)
|
Front
|
1550-1850
|
1710
|
1550-1850
|
1710
|
|
Rear
|
1590-2020
|
1590-2020
|
1590-2020
|
1590-2020
|
|
Wheel Base(mm)
|
2352
|
2352
|
2352
|
2352
|
|
Ground Clearance (mm)
|
476
|
425
|
476
|
425
|
|
Rated Traction Force(N)
|
17300
|
20800
|
17400
|
20900
|
|
Construction Mass(kg)
|
3155
|
3380
|
3155
|
3380
|
|
Min. Turning Radius(m)
|
4
|
4.8
|
4
|
4.8
|
|
Speed Range (km/h)
|
Forward
|
1.8-33
|
1.8-33
|
|
Reverse
|
4.5-14.9
|
4.5-14.9
|
|
Speed Range of Creeper Gear (km/h)
|
Forward
|
0.34-6.1
|
0.34-6.1
|
|
Reverse
|
0.8-2.7
|
0.8-2.7
|
|
Engine Specifications
|
Model
|
LR4M5-T67-U2
|
LR4M5-T67X1-U2
|
|
Type
|
4-cylinder, vertical, in-line cylinder arrangement, radiator cooling, 4-stroke cycle, direct injection
|
|
Rated Power (kw)
|
66.2
|
69.9
|
|
Fuel consumption (g/kw/h)
|
≤242
|
≤242
|
|
Rated Speed (rpm)
|
2300
|
2300
|
|
Bore ×Stroke (mm)
|
110×135
|
110×135
|
|
Total Displacement (L)
|
5.13
|
5.13
|
|
Drive System
|
Clutch
|
LUK, dual function, independent type
|
|
Gear Box
|
(3+1)×4 sliding gear shift
|
|
Main Drive
|
One pair of spiral bevel gears
|
|
Differential
|
Obturation, four bevel gears
|
|
Differential Lock
|
|
Mesh gear
|
|
Final Transmission
|
|
Planetary reduction gear
|
|
Traveling Mechanism
|
Tire
|
Front
|
7.5-20
|
13.6-24
|
7.5-20
|
13.6-24
|
|
Rear
|
16.9-34
|
16.9-34
|
16.9-34
|
16.9-34
|
|
Steering Gear
|
Full hydraulic power steering
|
|
Brake
|
Wet disc (Multiple)
|
|
Hydraulic System
|
Lifting Capacity at 610mm behind Lift Point (kg)
|
2500
|
2500
|
|
3-Point Suspension
|
Category: II
|
|
P.T.O. Shaft
|
Rotating Speed (rpm)
|
540/1000
|
|
Spline Size
|
6-ф35 rectangular spline
|
