Describe
Main Dispositions: Dual-function clutch Twin turning speeds of P.T.O. Power steering Saft start switch Fiberglass hood Combination meters Quality seat system Seat belt |
Options: Folding ROPS Sun shade Spring seat system Turf tyre Industrial tyre EPA Engine Hydraulic outlet |
Parameter
Model | DF-350 | DF-354 | |
Drive Type | 2WD | 4WD | |
Overall Dimensions | 3370×1500×1620(Height to steering wheel) | 3370×1500×1620(Height to steering wheel) | |
L×W×H(mm) | |||
Wheel Track(mm) | Front | 1,100,120,013,001,400 | 1200 |
Rear | 1100(Usually use),1200,1300,1400 | 1100(Usually use),1200,1300,1400 | |
Wheel Base(mm) | 1735 | 1739 | |
Ground | Under Front Axle | 420 | 358 |
Clearancre(mm) | Under Rear Axle | 378 | 378 |
Rated Traction Force(N) | In Paddy Fields | 4270 | 5160 |
6560 | 7230 | ||
In Dry Fields | 1290 | 1385 | |
Construction Mass(Kg) | 2.8 | 2.8 | |
Min. Turning Radius(m) | 1.66,2.74,4.41,5.92,8.62,14.20,22.85,30.68 | 1.74,2.80,4.40,5.92,9.02,15.54,22.85,30.68 | |
Theoretical Speed(Km/h) | Forward | 2.19,11.36 | 2.26,11.70 |
Reverse | TY395 | TY395 | |
Model | 3-cylinder,Upright inline cylinder | 3-cylinder,Upright inline cylinder | |
Type | radiator cooling,4-storke cycle,direct-injetion | radiator cooling,4-storke cycle,direct-injetion | |
Rated Power(Kw/hp) | 25.80/35.0 | 25.80/35.0 | |
Rated Fuel Consumption(g/kw/h) | ≤251.6 | ≤251.6 | |
Rated Speed(rpm) | 2400 | 2400 | |
Bore×Stroke(mm) | 95×105 | 95×105 | |
Total Displacement(L) | 2.23 | 2.23 | |
Clutch | Linkage type dual-function clutch | Linkage type dual-function clutch | |
Gear Box | (4+1)×2,plannar 3-shaft for main transmission epicyclic gearing for auxiliary transmission | (4+1)×2,plannar 3-shaft for main transmission epicyclic gearing for auxiliary transmission | |
Main Drive | One Pair of Spiral Bevel gears | One Pair of Spiral Bevel gears | |
Differential | Bevel Gear | Bevel Gear | |
Differential Lock | Jaw Lock | Jaw Lock | |
Final Transmissions | Spur Gear,External Gearing | Spur Gear,External Gearing | |
Tyre | front | 5.00-15 | 7.5-16 |
rear | 12.4-24 | 12.4-24 | |
Steering Gear | Hydraulic streering | Hydraulic streering | |
Brake | Disk type | Disk type | |
Hydraulic System | Lifting Capacity at | 580 | 580 |
610 mm Behind Lift | |||
Point(Kg) | |||
3-point Suspension | Category:I | Category:I | |
P.T.O.Shaft | Rotating | 540/1000 | 540/1000 |
Speed(rpm) | |||
Spline size | 6-φ35 Rectangular spline | 6-φ35 Rectangular spline |
